PATH-LENGTH  FOR  THE  SERVICES  -----   DRAFT

The Services Path-Length is calculated for the sub-detectors which we can define one tolerance on the length of 10% , for the others the integration layout do not allow to define this tolerance

The Path-Length is calculated for the different expected segments between :

                           Patch-Panel ----- Patch-Panel         and         Patch-Panel ----- Bottom of the Rack

In the Path-Length are not considerate :

                            the Patch-Cord Cable between the detector and the Patch-Panel

                            the length of the cables inside the Patch-Panel

                            the length of the cables between the Bottom of the Rack and the Crate




     THE  LENGTHS  AREN'T  UPDATED



ALICE-Servotech  :  CABLES -PATH  LENGTH  FORECAST           SIDE-A = RB24


POSITION on RB24 SPD SDD SSD FMD T0 V0 TPC TRD TOF HMPID EMC PHOS/CPV PMD
PATH-LENGTH (m) (m) (m) (m) (m) (m) (m) (m) (m) (m) (m) (m) (m)
Baby-Frame  (min…max)               2…10 2…10
Baby-Frame --- L3 Door               2 2
L3 Door --- Platform A/B               12 12
Platform A/B --- Rack               4 7
Correction for curves               2 2

Detector --- L3M                       2 2
L3M --- L3 Door                       5 5 (Crocus)
L3 Door --- RB24 Area-C                       20
RB24 Area-C --- Rack                       6
Correction for curves                       2

ITS  Services-Support 2.5 2.5 2.5 2.5
Mini-Frame (min…max) 1…4 1…4 1…4 1…4 1…4 1…4 2…6
Mini-Frame (front to back) 6 6 6 6 6 6 6           6
Mini-Frame --- RB24 Area-C 12 12 12       12           12
RB24 Area-C --- Rack 3 2 2       2           6
Correction for curves 2 2 2 1 1 1 2           2

Mini-Frame --- Platform A/B       20 20 20
Platform A/B --- Rack       5 7 10
Correction for curves       2 2 2

Mini-Frame --- CR4 80 80 80   80               80
CR4 --- Rack into CR4 2 4 6   6               7
Correction for curves 2 2 2   2               2

L3 Door --- CR4             70 70 70
Rack Platform A/B --- CR4         55 58   57 60
CR4 --- Rack into CR4         6 6 8 8 6
Correction for curves         2 2 2 3 3

Detector --- L3M                   2 2
L3M --- L3 Door                   5 5
L3M Door --- Platform A/B                   12 12
Platform A/B --- Rack                   6 6
Platform A/B --- CR4                   60 60
Correction for curves                   2 2
